Automatic case taper
1.Automatic upper flap-folding
2.Easy operation
3.New type of tape head
4.Both side compression rollers for tight sealing
5.Top mast with cushion for smooth sealing
6.Tape overlap length 60±5mm
7.Two-side belt driven with universal bearing: Precise, Low noise,Durable parts and belt
8.Caster with brake
9.Equipped with control valve type, different size carton no manual adjustment, especially suitable for production line
- Overview
- Recommended Products
Overview
1.Automatic upper flap-folding
2.Easy operation
3.New type of tape head
4.Both side compression rollers for tight sealing
5.Top mast with cushion for smooth sealing
6.Tape overlap length 60±5mm
7.Two-side belt driven with universal bearing: Precise, Low noise,Durable parts and belt
8.Caster with brake
9.Equipped with control valve type, different size carton no manual adjustment, especially suitable for production line
Parameter
Power Supply |
1PH 110V/220V 50/60Hz |
Power Consumption(W) |
374 |
Tape Width |
2or 3 |
Tape I.D. |
φ76 |
Tape O.D. |
280mm (T0.05mm*L1000 yd) |
Driven Belt |
Two-Side |
Belt speed(M/min) |
20(M/min) |
Sealing Speed (Carton/h) |
700 (L300*W300*H300mm) |
Loading Weight (kgs) |
Max. 30 |
Height(mm) |
570-810 |
Machine dimensions L*W*H |
L2076*W1002*H1551-1881 |
Packaging dimensions L*W*H |
L2147*W1058*H1524 |
Machine weight(kgs) |
N.W 310 G.W. 395 |
