High speed shrink wrapping machine
PE film group packing machine is suitable for wrapping of such products as pop-top, mineral water, bottles, beer, drinks etc without bottom-tray, working with PE shrink tunnel to pack the goods perfectly, the whole producing process adopts the Germany advanced technology, and the main parts are imported from international famous companies, Capability stable and using long-time.
- Overview
- Recommended Products
Overview
PE film group packing machine is suitable for wrapping of such products as pop-top, mineral water, bottles, beer, drinks etc without bottom-tray, working with PE shrink tunnel to pack the goods perfectly, the whole producing process adopts the Germany advanced technology, and the main parts are imported from international famous companies, Capability stable and using long-time.
Parameter
Model |
MB-10 |
Dimension for The Whole Unit |
L10000mm*W 1100mm*H 2100mm |
Thermal Shrinkage Passage Dimension |
L2400mm*W 650mm*H 450mm |
Max Package Dimension |
L600mm*W 400mm*H 350mm |
Packaging Speed |
10-15 bags/minute |
Transfer Belt Width |
550mm |
Sealing And Cutting Time/Temperature |
0.5-1s around 180 ℃ -260 ℃ |
Operating Power Supply/Power |
3 phase 380V 24KW |
Operating Air Pressure |
0.6-0.8 Mpa |
Air Consumption |
0.6m3/min |
