Beverage mixer
QHS mode mixing machine is designed with latest technology and used for the mixing of soda and other aerated beverage. The pates that contact the liquid ate all made of fine low carbon stainless steel in accordance with the requirement of food sanitation. PLC technology is adopted to control the pressure and liquid level in the vat. An alarm will be given if there is anything abnormal and the machine has a compact structure. With stable performance and high efficiency, it is easy to operate. It is an indispensable piece of equipment in beverage production.
- Overview
- Recommended Products
Overview
QHS mode mixing machine is designed with latest technology and used for the mixing of soda and other aerated beverage. The pates that contact the liquid ate all made of fine low carbon stainless steel in accordance with the requirement of food sanitation. PLC technology is adopted to control the pressure and liquid level in the vat. An alarm will be given if there is anything abnormal and the machine has a compact structure. With stable performance and high efficiency, it is easy to operate. It is an indispensable piece of equipment in beverage production.
Parameter
Model |
QHS-1500A |
QHS-3500A |
QHS-3000 |
QHS-5000 |
QHS-7000 |
QHS-10000 |
QHS-15000 |
Capacity |
1000-1500 |
2000-3500 |
2000-3000 |
4000-6000 |
8000-9000 |
10000-12000 |
12000-16000 |
Mixing range |
1:3-1:6 |
||||||
Gas content in beverage |
1.5-2.5 |
>3.0 |
>3.5 |
||||
Temperature in chilled water |
0-5℃ |
0-4℃ |
|||||
Water deoxindization method |
Deoxidized by CO2 |
Deoxidized by vacuum system |
|||||
Working pressure of pre-carbonation tank and syrup tank |
0.05-0.05 |
Pre-carbonation tank:-0.05~-0.06Mpa |
|||||
Syrup tank:-0.05~-0.08Mpa | |||||||
Working pressure in storage tank |
0.2-0.5 |
||||||
Power supply(Mpa) |
1.1 |
1.5 |
3.7 |
5.2 |
8.5 |
11 |
15 |
Overall dimension |
900*700 *2000 |
1100*900 *2100 |
1600*1250 *2100 |
2000*1200 *2100 |
3200*2100 *2500 |
3800*2200 *2750 |
4300*2200 *2550 |
Weight(kg) |
500 |
650 |
1200 |
1800 |
2800 |
4800 |
6500 |
