PET bottle juice filling machine
The automatic juice filling machine integrated machine is a new product developed by BIEVO Machinery after introducing internationally advanced technology to meet market demand.The juice filling equipment adopts automatic washing-filling-capping, suitable for 330-1500ml small bottle juice production line.
- Overview
- Recommended Products
Overview
The automatic juice filling machine integrated machine is a new product developed by BIEVO Machinery after introducing internationally advanced technology to meet market demand. The juice filling equipment adopts automatic washing-filling-capping, suitable for 330-1500ml small bottle juice production line.
It enhances production capacity with precise and rapid filling, accommodates various bottle sizes and shapes, and employs advanced technology to maintain juice quality. With a user-friendly control panel, robust construction, and a hygienic design for easy cleaning, it ensures reliable and safe operation. This machine is ideal for beverage producers seeking a versatile and dependable solution for high-volume juice production.
Applicable Products: Juices, tea drinks, functional drinks, milk drinks, etc.
Suitable Container: PET bottles of various shapes and capacities
Filling Modes: Hot filling
Production Capacity: 2000-25000 BPH
Parameter
Model |
RGZ12-12-6 |
RGZ18-18-6 |
RGZ24-24-8 |
RGZ32-32-8 |
RGZ40-40-10 |
RGZ50-50-12 |
RGZ60-60-15 |
Production capacity(bph)(500ml) |
2000-4000 |
4000-6000 |
8000-10000 |
10000-13000 |
14000-16000 |
17000-20000 |
20000-25000 |
Way of filling |
Gravity micro negative pressure filling |
||||||
Filling feedback quantity |
≤8% |
||||||
Applicable bottle type |
Bottle diameter:50-100mm height:150-320mm volume:330-1500ml |
||||||
Suitable Cap Standard |
Plastic Screw Cap |
||||||
Gas source pressure(Amp) |
0.6 |
||||||
Gas consumption(m3/min) |
0.4 |
0.4 |
0.6 |
0.6 |
0.6 |
0.8 |
0.8 |
Total power(kw) |
4.6 |
4.6 |
6.4 |
7 |
11 |
12 |
15 |
Weitht(kg) |
2500 |
3300 |
4800 |
6000 |
8000 |
9500 |
12300 |
Dimension(L*W*H)(mm) |
2450*1650*2100 |
2600*1800*2100 |
3000*2200*2400 |
4000*2220*2400 |
4100*2700*2600 |
4500*3400*2600 |
5400*4100*2600 |
Feature
Stable Bottle-Neck Clamping: The suspending bottle-neck clamping design make the bottle stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production of different types of bottles easily.
Stainless Steel Grab: The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle’s screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
Fast & Stable Gravity Filling: The advanced gravity filling technology used in this machine makes the filling quick, steady and accurate.
Magnetic Torque Capping: Magnetic torque is used for screw capping, and the power of screw capping can be adjusted steplessly.Capping is reliable and do no harm to the caps.
Smart Control System: Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this machine.
Premium Materials & Components: All parts that have direct contact with the water are made of high quality stainless steel. The critical electricat components are from famous international companies,such as Mitsubishi, Omron to name a few.
